Durlon® 9000N is for use in process piping and equipment in chemical, pulp & paper, food & beverage and other general industrial applications where resistance to highly aggressive chemicals is required. In addition, the shape of the fillers do not allow wicking which can cause corrosion on flange surfaces and conforms to FDA requirements.
|Industries||Chemical Processing , Food & Beverage , Marine , Mining , OEM Services , Oil & Gas , Pharmaceutical , Power Generation , Primary Metals , Pulp & Paper , Rail Tank Car , Water & Wastewater|
Durlon® 9000 is made with Teflon™ fluoroplastic. Teflon™ is a trademark of The Chemours Company FC, LLC used under license by Triangle Fluid Controls Ltd.
|Pressure, max, bar (psi)||103 (1,500)|
|Density, g/cc (lbs/ft3)||2.2 (138)|
|Creep Relaxation, %||30|
|Tensile Strength, MPa (psi)||13.8 (2,000)|
ASTM 2378 (Nitrogen)
|Volume Resistivity, ohm-cm ASTM D257||1.0 x 105|
|Dielectric Breakdown, ASTM D149, kV/mm (V/mil)||16 (406)|
Note: ASTM properties based on 1/16″ sheet thickness except ASTM F38, which is based on 1/32″ sheet thickness. This is a general guide only and should not be the sole means of accepting or rejecting this material. The data listed here falls within the normal range of product properties but should not be used to establish specification limits nor used alone as the basis of design.
*For applications above Class 300, consult your representative.
|USP Class VI||Met requirements for Plastic Class VI – 121°C (250°F)|
|FDA||Conforms to the requirements of 21 CFR 177.1550 for food and drug contact|
|(EC) 1935/2004 & EU (10/2011)||Approved Material|
|Y psi (MPa)||1,937 (13.4)||1,639 (11.3)|
|Gb psi (MPa)||639 (4.4)||495 (3.4)|
|Gs psi (MPa)||55 (0.379)||65 (0.448)|
